The best for reflective surfaces
Designed for demanding applications, the Zephyr II Blue 3D scanner performs accurate and fast measurements. The blue laser is optimized for reflective surfaces or even dark parts. 3D scanners Zephyr II can be integrated on any system: measuring arm, CMM, or even robot.
All CMMs can work with this 3D scanner.
The software and controllers in the list below ensure a complete compatibility.
Software: Geomagic, PolyWorks, ArcoCAD, Capps DMIS, Rational DMIS, Inca3D etc.
Controller: Metrologic, Renishaw, Pantec, Deva etc.
FEATURES
Ready for CMM retrofit
Blue laser
Kreon plugins for third party software
Auto Quality Check
Renishaw compatible
Ace Zephyr II Blue scanning arm
Zephyr II Blue attached to Ace arm measuring arm provides a high accuracy scanning solution. This package, fully designed for performance, is dedicated to shiny parts scanning. When being combined with the Ace arm, the scanner is housed in black and red and perfectly matches the design of the Ace in order to create a sophisticated, streamlined design.
| Scanner specifications | ||
|---|---|---|
| Zephyr III 150 | Zephyr III 50 | |
| Max scanning speed | 600.000 pts/sec | 600.000 pts/sec |
| MPE (P[Size.Sph.All:Tr:ODS]) | 14 micron | 5 micron |
| MPL (P[Form.Sph.D95%:Tr:ODS]) | 15 micron | 8 micron |
| MPL (P[Form.Pla.D95%:Tr:ODS]) | 20 micron | 10 micron |
| Max laser line width | 150 mm | 50 mm |
| Max frequency | 300 Hz | 300 Hz |
| Laser line color | Blue 2M | Blue 2M |
| Line resolution | 50 micron | 15 micron |
| Stand-off distance | 85 mm | 95 mm |
| Field of view | 110 mm | 40 mm |
| Temperature compensation | Yes | Yes |
